Display Flex Cable for Dell Latitude 7490 E7490 with IR Camera PTVXY DC02C00GR00 - 30 pin eDP Non-Touch
€18.98
Tax included
The PTVXY display flex cable is a replacement part for Dell Latitude 7490 and E7490 laptops with a 30-pin eDP connector. Designed for non-touch screens with an infrared (IR) camera, it is compatible with part numbers such as DC02C00GR00. New, with a 3-year warranty and 24-48h shipping.
PTVXY
Display Flex Cable for Dell Latitude 7490 E7490 with IR Camera PTVXY DC02C00GR00 - 30 pin eDP Non-Touch
New component for non-touch screens with infrared (IR) camera. 30-pin eDP connector.
- For Dell Latitude 7490 / E7490
- 30-pin eDP Connector
- For Non-Touch screen with IR Camera
- New
Key features
-
Specific Compatibility
Designed for Dell Latitude 7490 and E7490 with IR camera and non-touch screen.
-
Display Connector
30-pin eDP connector with 0.5 pitch for stable video transmission.
-
Camera Connection
Includes 6-pin connection for the infrared (IR) camera.
-
New Component
Completely new replacement part, ensuring optimal performance and durability.
Product description
The LCD video flex cable with reference PTVXY / DC02C00GR00 is an essential replacement component for the connection between the motherboard and the display in Dell Latitude 7490 and E7490 laptops. This cable is specifically designed for configurations with a 14.0-inch non-touch screen and incorporating an infrared (IR) camera.
It features a 30-pin eDP display connector and a 6-pin camera connector, ensuring stable and reliable video and camera data transmission. It is crucial to verify that the part numbers and specifications match your original cable to avoid incompatibility issues that could damage the motherboard or the screen.
- Display Connector Type: eDP 30 pins
- Camera Connector Type: 6 pins (IR)
- Screen Compatibility: Non-Touch
- Condition: New component
Important note: Due to the delicate nature of this component, if the security seal of the flex cable is removed or tampered with, the product cannot be returned. Make sure it is the correct component before opening it. If you have doubts, contact our technical support.
Who is this product for?
For technical services and advanced users who need to replace a damaged display cable in a Dell Latitude 7490, restoring image and IR camera functionality.
Ideal for
- Repair of screen with flickering or no image on a Dell Latitude 7490.
- Replacement of a flex cable damaged during a previous disassembly.
- Solution to infrared (IR) camera detection problems.
- Replacement of PTVXY or DC02C00GR00 cable due to failure or wear.
Technical specifications
| Conector de Pantalla | eDP 30 pins |
|---|---|
| Paso del Pin | 0.5 Pitch |
| Conector de Cámara | 6 pins |
| Marca | Dell |
|---|---|
| Modelos | Latitude 7490, E7490 |
| Tipo de Pantalla | Non-Touch |
| Cámara | Infrared (IR) |
Compatibility
Compatible part numbers
- PTVXY
- 0PTVXY
- CN-0PTVXY
- DAZ40-EDP-CABLE-NTS-IR
- DC02C00GR00
- DAZ 40_3-5MM_CAM
- DB-2209
Compatible laptop models
- Dell Latitude 7490
- Dell Latitude E7490
Always check the part number printed on your original part before ordering; if in doubt, contact us with the exact model of your device.
Frequently asked questions
Is this cable compatible with my Dell Latitude 7490 with a touch screen?
No, this flex cable with reference PTVXY is designed exclusively for Dell Latitude 7490 and E7490 models that come equipped with a non-touch screen. Touch screen models use a different connector and wiring. Verify your equipment's specifications before purchasing.
My original cable has part number DC02C00GR00. Is this PTVXY a valid replacement?
Yes, part numbers PTVXY and DC02C00GR00 are equivalent and fully compatible with each other for the Dell Latitude 7490 with a non-touch screen and IR camera. You can use this cable as a direct replacement for your original part without compatibility issues.
What should I consider when installing this cable?
Installation requires care. It is essential to disconnect the laptop battery before handling any internal components to avoid short circuits. Handle the cable delicately, ensuring that the connectors are fully seated without forcing them. Improper connector seating can damage both the cable and the motherboard.
What warranty does it have and what happens if I open it and it's not the correct one?
The cable has a 3-year warranty for private customers (1 year for professionals). However, due to its nature, if the packaging's security seal is broken or tampered with, the product cannot be returned. Please ensure that the part number and characteristics match your part before opening it.
How long does it take to arrive if I order it for Madrid?
We ship from Spain. For orders to Madrid and the rest of the peninsula, the delivery time is 24 to 48 business hours. Orders placed before 4:00 PM are prepared on the same day, speeding up delivery.
Warranty, returns and shipping
- Warranty: 3-year warranty (1 year for business customers)
- Returns: 14-day returns (ship it yourself or €8.90 home pickup in Spain and Portugal)
- Shipping: EU delivery 48-120 h
- Condition: New
FLEX-1766
Data sheet
- Compatibility
- Dell Latitude 7490, Dell Latitude E7490
- Screen Pin
- Camera Pin
- Flex Type
- Non Touch
- Connector Type
- CG. Reference
- PTVXY
- CG. Type of piece
- Screen Flex Cable
- CG. State
- New
- CG. Warranty
- 3 years
New
☆☆☆☆☆
